CE TOOLING STEELS USED FOR TOOLS |
|
CE Tooling strives to produce tooling to the highest standards. The steels used to mfg. our tools are of the best quality grades available to produce tooling capable of standing up under various punching conditions. Our heat treating facilities are advanced to produce consistent quality assured hardening of steels to their optimum state. Longevity of tool edge life, labor saving operational features, realistic balance of Tool Life, and Tool Cost! |
|
BRAKE TOOLS Designed and produced to the highest quality Steels are selected based on proven high strength, toughness, and deep harden ability.
Precision-Planed: SAE 4140 (42CrMo4) 26-30Rc Further Option Induction/Flame Hardened to 45-49 Precision-Ground: Induction hardened CK50 50-56Hrc & DIN 17200, ISO 683 53-60Hrc |
|
PUNCH TOOLS |
Punch |
Dies |
|
Di-Acro 901, 902, 903 |
A2 / S7 |
A2 |
|
Salvagnini SA |
HSS-M2 |
D2 |
|
Thick Turret AT |
D2 or HSS-M2 |
D2 |
|
Thin Turret ST & AS |
D2 or HSS-M2 *Semi-HSS on 3-1/2” slotting tools |
D2 |
|
Trumpf TR |
M2 & M4 -HSS D2/A2 4142 |
D2 |
|
Wiedemann 4W 2W 2B |
4W=HSS-M2 or A2, 2W & 2B = A2 |
A2 or S7 |
|
Whitney RP, 28XX, 36tc 28 RP 36 |
RP & 28XX= A2 36tc=Sta. 0 insert=M2, Size 1=A2, 2&3 A2&S7 |
A2 |
